Chapter 3 Settings and Measurement
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
Main operations to replay captured data
SPAN/POSITION/TRACE replay Press the “ENTER” key to open the [SPAN/POSI/TRACE] settings and change the
settings.
Operation in the menu during data capture
Perform cursor movement and data search with the [MENU] key.
Cursor movement You can switch between cursors A and B using the [CURSOR] key.
Using the " " or " ", " " keys, move the cursor.
Data save Save all the data or data between cursors with the [FILE] key.
Time axis change Change the time axis scale with the [TIME/DIV] key.
File operation Using the [FILE] key, perform file-related operations.
Display cop Copy the screen with the [FILE] key.
Alarm History Display the Alarm History with the [DISPLAY] key and move the cursor to the alarm point.
•
For CSV-formatted data, only the data captured by this GL860 can be replayed. Also, when the data captured in CSV
format is replayed, the unit of the temperature data is displayed in “deg C” rather than “°C”.
•
Alarm History is available only when the alarm history file exists in the same folder as the data.
CAUTION
