3-24
Chapter 3 Settings and Measurement
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
Setting Selections available
Analog
Input Standard terminal / Screwless
terminal
/
Withstand high-voltage
high-precision terminal
Off, DC, TEMP, RH
Standard 20CH screw
terminal (B-563)
Standard 20CH
screwless terminal
(B-563SL)
Standard 30CH
screwless terminal
(B-563SL- 30)
Range Voltage 20
・
50
・
100
・
200
・
500mV
、
1
・
2
・
5
・
10
・
20
・
50
・
100V
、
1-5V
Temperature Sensor Thermocouple: TC-K
・
TC-J
・
TC-T, TC-R, TC-E, TC-B, TC-S, TC-N,
TC-C
Range 100
・
500
・
2000℃
Humidity 100% fixed
Filter Off, 2, 5, 10, 20, 40
Withstand high-
voltage high-precision
terminal (B-565)
Range Voltage 20
・
50
・
100
・
200
・
500mV
、
1
・
2
・
5
・
10
・
20
・
50
・
100V
、
1-5V
Temperature Sensor Thermocouple: TC-K
・
TC-J
・
TC-T
・
TC-R
・
TC-E
・
TC-B
・
TC-S
・
TC-N
・
TC-C
Resistance bulb: Pt100
・
JPt100
・
Pt1000
Range 100
・
500
・
2000℃
Humidity 100% fixed
Filter Off
・
2
・
5
・
10
・
20
・
40
EU
(Scaling settings)
Function Off, On
* When measuring the humidity, “Off” is fixed.
Meas.
Value
Upper limit Set numeric value
Lower limit Set numeric value
EU output Upper limit Set numeric value
Lower limit Set numeric value
Dec pt EU output upper limit × 0.01, × 1, × 10, × 100, × 1000
Select Voltage, Current, Length, Area, Volume, Velocity, Accel, Freq, Mass,
Energy, Pressure, Flow, Temp, Strain, Brightness, Concentration
Unit (The selections vary depending on the unit selected in the above.)
Arbitrary unit Enter text (Max. 8 characters)
Misc. Annotation text string Enter text (Max. 31 characters)
Span
settings
Upper limit Set numeric value
Lower limit Set numeric value
Waveform color setting 0 to 31 for each of red, green, blue (RGB)
Line Thickness Setting 1 to 8 dots
Trace setting Off, On
Perform Auto Zero ADJ. Press the right key to execute.
* This function is not available for the temperature setting.
Reset Auto Zero ADJ. Press the right key to execute.
* This function is not available for the temperature setting.
