Chapter 3 Settings and Measurement
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
1-2. Sensor
This is used to select the type of thermocouple to be connected when the temperature is input.
Terminal Unit Selection item Description
Standard 20CH screw terminal
(B-563)
Standard 20CH screwless
terminal (B-563SL)
Standard 30CH screwless
terminal (B-563SL-30)
Sensor Thermocouple: TC-K
・
TC-J
・
TC-T
・
TC-R
・
TC-E
・
TC-B
・
TC-S
・
TC-N
・
TC-C
Withstand high-voltage high-
precision terminal (B-565)
Thermocouple: TC-K
・
TC-J
・
TC-T
・
TC-R
・
TC-E
・
TC-B
・
TC-S
・
TC-N
・
TC-C
Resistance bulb: Pt100
・
JPt100
・
Pt1000
1-3. Range
This is used to select the range of measurement.
Input item Description
DC 20, 50, 100, 200, 500mV; 1, 2, 5, 10, 20, 50, 100V 1-5V
TEMP 2000, 500, 100℃
* The resolution varies depending on the range.
RH No selection available
Available SPAN Settings
<Voltage Ranges>
Range Maximum SPAN Minimum SPAN Minimum Resolution
20mV
-
22.000 to +22.000mV 0.200mV 0.001mV
50mV
-
55.00 to +55.00mV 0.50mV 0.01mV
100mV
-
110.0 0 to +110.0 0 mV 1.00mV 0.01mV
200mV
-
220.00 to +220.00mV 2.00mV 0.01mV
500mV
-
550.0 to +550.0mV 5.0mV 0.1mV
1V
-
1.1000 to +1.1000V 0.0100V 0.0001V
2V
-
2.2000 to +2.2000V 0.0200V 0.0001V
5V
-
5.500 to +5.500V 0.050V 0.001V
10V
-
11.000 to +11.000V 0.10 0V 0.001V
20V
-
22.000 to +22.000V 0.200V 0.001V
50V
-
55.00 to +55.00V 0.50V 0.01V
100V
-
110.0 0 to +110.0 0V 1.000V 0.01V
1-5V
-
5.500 to +5.500V 0.050V 0.001V
