1-7. Logic / Pulse
This is used to select the processing method for digital input.
Selection item Description
Off Digital input measurement is disabled.
Logic Digital input is processed as logic signals.
Pulse Digital input is processed as pulse signals.
1-8. Input
This is used to set the pulse measurement mode. This setting is available only if Pulse is selected in "1-7. Logic / Pulse".
Selection item Description
Off Pulse input measurement is disabled.
Revol. The number of pulses per sample interval is counted and converted to the number of revolutions per minute.
Counts Captures the cumulative number of pulses for each sampling interval from the start of measurement.
Inst. Captures the number of pulses for each sampling interval.
*Depending on the recording environment, it may take a long time to write files during recording.
If writing takes a long time, reduce the number of channels or adjust the sampling interval.
1-9. Filter
This is used to set the filter for input.
Selection item Description
Off Disables hardware filter.
On Enables hardware filter. It is effective in a noisy environment.
The filter is approximately 30 Hz (-3 dB).
1.10 Slope
This is used to set the slope (direction) to count the number of pulses. This setting is available only if Pulse is selected
in "1-7.M ode".
Selection item Description
H Counts the rising edges of pulses.
L Counts the falling edges of pulses.
