3-39
Chapter 3 Settings and Measurement
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
5. When the settings are copied, the copy mode ends.
If you change the type of the copy source CH (Analog, Logic/Pulse, or Math), the copy destination selection that was
previously selected will be cleared.
(1)-16 How to specify the copy channel range
1. Start copying the AMP tab.
2. Open the CH range selection.
3. Set the range of source and destination CHs, then press “OK.”
If you clear the selection, the currently selected CH will be cleared and you will return to the previous screen.
4. Verify that the source CH has an “*” mark and the destination CH has an “>” mark and click Execute.
