The inverse display between "BAT1" and "BAT2" visualizes the quality
of the incoming signal from the transmitter in%.
The current cell voltages of the maximum 7-cell battery packs con-
nected to the balancer connection 1 (L) and / or 2 (H) are alternately
shown on the right-hand edge.
It have the following meanings:
Value Description
ON Current control ON
V Current voltage
A Momentary current
BAT1/BAT2 BATT 1 and BATT 2
ALT Current altitude
m/1s 
m/3s 
100 Signal quality in % (RX-S QUA)
T1 / T2 Temperature of sensors 1 and 2
L or H Cell voltage of cells 1... 14
L = Balance port 1
H = Balance port 2
Microcopter display
This display shows the data of a HoTT-compatible microcopter. The
abbreviations have the following meaning (from top to bottom start-
ing on the left):
Value Description
V Current voltage
0:00 Time turned on
mAh Used battery charge since the device has been
turned on
0 Position number of the satellite
km/h Speed above ground calculated by the GPS sys-
tem
Alt Current altitude
Dir Direction of movement
I Momentary current
m Distance from the starting location calculated by
the GPS system
° Position in angular degrees relative to the starting
location calculated by the GPS system
