Model types/Phase
Push the ENT key to recall the selection menu from the base display.
Push the ESC key to stop the procedure.
Select the desired menu with the selection buttons, then press the
ENT button again to recall the list of the submenu Model Type /
Phase.
In this menu the "type" of the model to be programmed is defined.
This also activates all the mixers, coupling functions, etc. character-
istic of the type of the model, which are defined for the subsequent
programming.
Note
The submenu "Phase trim" is only visible and selectable with the
model type "Airplane".
Model type (Air, land and water models)
Motor on CH1
"None"
No drive motor is installed in the active model.
The brake system is retracted in the front position of the throttle /
brake control stick (CH1), and the mixers "CH1 => N.N. *" in the
"Wing mix" menu are activated.
The warning "Throttle too high!" is deactivated and the "Throttle
cut" option is not shown in the display.
"back"
The idle position of the throttle/brake control stick (CH1) is in the
backward position, in the pilot direction. The warning "Throttle too
high!" is activated and the "Throttle cut" option is shown in the dis-
play.
"Front"
The idle position of the throttle/brake control stick (CH1) is in the
forward position, in the opposite direction of the pilot. The warning
"Throttle too high!" and the "Throttle cut" option in this menu are
active.
"None/inv"
No drive motor is installed in the active model.
M o d e l
m e m o r y
D / R
E x p o
T x
s e t t i n g
C t l
s e t t i n g
S e r v o
s e t t i n g
W i n g
m i x
M . T y p e
P h a s e
C 1
c u r v e
Model type
Phase setting
Phase trim
=>
=>
=>
=>
=>
Tail
Motor at C1
normal
back
Aile./Flap 1AI
M.Stop
–––
+150%–100%
* N.N. = Nomen Nominandum (the name to be called)
