Vario
This display shows the data about altitude in meters related to launch
so as the the current climb/sink rate in m/s, from the connected
vario.
Text displays
Depending on the availability of the corresponding sensors, text can
be displayed with 2 x 10 or 3 x 7 characters in the following two dis-
plays.
GPS
This display shows the data of a GPS module with an integrated
Vario module connected to the receiver (No. 33600).
In addition to the current position data and model speed in the cen-
ter of the display, the current height is displayed in relation to the
starting location along with the ascent and descent of the module in
the starting location are also shown.
Note
As long as the two data fields are black on the lower right, no cur-
rent GPS data is available.
It have the following meanings:
Value Description
W/N/E/S West / North / East / South
Kmh Speed over ground
RXSQ Transmitter signal quality received by the receiver
expressed as percentage.
DIST. Distance
ALT Current height relative to the starting location
m/1s
m/3s
