Lim
By the assignment of a control, for example of the control "DG", the
option "Throttle limit" can be activated.
With an active throttle limiter, the increase of the system speed
below the hover point is much more flexible and finer to optimize
than by the so-called "Throttle selection" of other remote control
systems. In addition, the programming of a "Throttle selection"
phase, which is ultimately exclusively used to start the engine,
becomes superfluous.
Programming step-by-step
1. Use the selection buttons to select the input to be set.
2. Push the ENT key.
3. Assign the throttle limit control, e.g. the DG proportional rotary
control.
4. Push the ENT key.
5. Move to the "- Trv +" column with the selection keys.
6. Turn the control clockwise as far as the stop, so that the right
value field of the column "- trv +" is framed.
7. Use the selection buttons to increase the value of the framed field
to +125%.
 This setting ensures that the full throttle position, accessible
through the throttle curve setting of the "Helicopter mix"
menu is not limited in any way.
8. Push the ESC key to stop the procedure.
Dual Rate / Expo
Select the desired menu using the selection buttons and then press
the ENT button to enter the setup page of the menu.
Push the ESC key to stop the procedure.
The dual rate/expo function allows you to switch or influence the
control deflections and characteristics for the control functions of
the control functions 2 … 4. The basic functionality is the same in all
of the five model types. Only the names of the three lines listed
below are different:
Line 1 AI Roll ROLL ST ST
Line 2 EL Nick NICK CH3 CH3
Line 3 RU Tail YAW CH4 CH4
E8
E9
+
Trv
+100%
+100%
+100%
+100%
free
free
E10 +100%
+100%free
E11 +100%
+100%free
Lim +100%
+100%free
E8
E9
+
Trv
+100%
+100%
+100%
+100%
free
free
E10 +100%
+100%free
E11
+100%
+100%
free
Lim +100%
free
+125%
Model
memory
Tx
setting
M.Type
Phase
Servo
setting
Ctl
setting
D/R
Expo
Wing
mix
C1
curve
