RX SERVO TEST
In this menu, you can use the RX SERVO TEST function to test the
servos connected to the currently active receiver, set voltage and
temperature limits, and influence the signal output.
Value Description Possible settings
Vx.xx Firmware version of
the receiver
None
ALL-MAX Servo travel on
the "+" side for all
servo outputs for the
servo test
ALL-MIN Servo travel on
the "–" side for all
servo outputs for the
servo test
TEST Test procedure START / STOP
ALARM
VOLT
Alarm threshold for
the receiver’s low
voltage warning
ALARM
TEMP+
Alarm threshold
when the receiver
temperature is too
high
50 … 80°C
Factory setting: 55°C
ALARM
TEMP–
Alarm threshold
when the receiver
temperature is too
low
-20 … +10°C
Factory setting: -10°C
CH OUT-
PUT TYPE
Channel sequence or
type of aggregate
symbol
ONCE, SAME, SUMI, SUMO
and SUMD
Servo test function
ALL-MAX (servo travel on the "+" side)
In this line, set the maximum servo travel on the plus side of the con-
trol travel for the servo test.
Make sure that the servos do not strike anything during the test rou-
tine.
ALL-MIN (servo travel on the "–" side)
In this line, set the maximum servo travel on the minus side of the
control travel for the servo test.
RX SERVO TESTV6.37
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
TEST : STOP
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
CH OUTPUT TYPE:ONCE
