"Delta/flying wing"
This option is only suitable for Delta and Flying wing models.
The aileron and elevator control are carried out through one or two
servos each half-wing. The elevator and aileron trim acts according
to your settings of "2AI 2FL" only on the servos 2 + 3, see table below.
"2 EL sv"
This option is indicated for models with 1 or 2 aileron and two ele-
vator servos. When the elevator control is actuated, the servo con-
nected to the output 8 works in parallel with servo 3. The elevator
trim acts on both servos.
Ailerons/Flaps
In this line you can select the number of servos installed in the wings.
The following table shows the control channels to which the servos
must be connected.
Control surfaces count Occupied control channel
1AI 2
1AI 1FL 2 | 6
2AI 2 + 5
2AI 1FL 2 + 5 | 6
2AI 2FL 2 + 5 | 6 + 7
Programming Aile./Flap step-by-step
1. Select the line using the selection keys.
2. Push the ENT key.
3. From the list, select the appropriate count of ailerons and flaps
for the model.
4. Press the ENT key to complete the operation.
According to this scheme the related required mixing options are
activated in the "Wing mix" menu.
Tail
Motor at C1
normal
back
Aile./Flap 1AI
M.Stop
–––
+150%–100%
