87 / 116
S1002.PRO_mz12PRO_Teil2_V1sh
RX FREE MIXER
Up to five mixers can be programmed in the receiver.
Value Description Possible settings
Vx.xx Firmware
version of the
receiver
None
MIXER Mixer selection 1 … 5
MASTER
CH
Signal source or
source channel
0, 1 … according to the receiver
SLAVE CH Target channel 0, 1 … depending on the receiver
S-TRAVEL– Mixing on the
"–" side of the
servo travel in
percentage
servo travel
S-TRAVEL+ Mixing on the
"+" side of the
servo travel in
percentage
servo travel
RX WING
MIXER
TAIL TYPE
Tail type NORMAL,
V-TAIL (V-LW)
ELEVON
(elevator/aileron mixer for delta
and flying wing)
MIXER
Note
If mixing functions have already been programmed or planned in
the "Mixer" or "Free Mixer" menu, it is imperative that these mixers
do not overlap with those of the "RX FREE MIXER" menu!
MASTER CH ("from")
According to the same principles described in the section "free
mixer", the signal at MASTER CH (signal source or source chan-
nel) can be mixed with the SLAVE CH (target channel) to the adjust-
able amount.
The default setting "00" must be selected or left if no mixer is to be
set.
SLAVE CH ("to")
The signal of the MASTER CH (signal source or source channel) is pro-
portionately mixed with the SLAVE CH (target channel). The level of
mixing is determined by the percentages entered in the "TRAVEL–"
and "TRAVEL+" lines.
RX FREE MIXERV6.37
MASTER CH: 00
SLAVE CH : 00
S–TRAVEL–: 100
S–TRAVEL+: 100
MIXER : 1
RX WING MIXER
TAIL TYPE: NORMAL
