Gyro
Most of the current gyro systems can be adjusted for a smooth, pro-
portional effect; you can also choose between two different modes
of action by the transmitter.
If the Gyro currently used in the model also has at least one of these
options, this option offers the possibility of "normal" Gyro action as
well as "Heading Lock" operation, analogue to the control centre
adjustment or offset adjustment of other remote control systems.
The adjustment range of the "Gyro" line is ±125%.
SP limit
In the mz-12 Pro HoTT transmitter, the relevant software function
offers a limitation of the swashplate deflection that can be adjusted
between any combination of circular and square. This means that
the limitation of the maximum tilting angle of the swash plate is pro-
portionally variable between 100% - the deflection is circularly lim-
ited to the value attainable with roll or pitch alone - and 149% - no
limitation effective. In addition, this function can also be deactivated
completely by selecting "off". The SP limiter can be adjusted accord-
ing to the phase.
Speed controller on CH8
If a speed controller is used, this is usually connected to output 8 and
the value field of this menu line must be set to "yes".
Programming step-by-step
1. Push the ENT key to activate the value field.
2. Use the selection keys to set "yes" or "no".
3. Press the ENT or ESC key to complete the input.
Note
If the setting "yes" is chosen, the control channel 8 cannot be used
otherwise.
normal
0%
0%
Tail
Thr
Thr
Roll
Thr
Nick 0%
Gyro suppression
0%
Gyro 0%
normal
0%
0%
Thr
Roll
Thr
Nick
0%Gyro suppression
0%
Gyro
OFF
SP limit
normal
0%
Gas
Nick
0%Kreiselausbl.
0%
Gyro
AUS
TS-Limit
Regler an K8
nein
