S1002.PRO_mz12PRO_Teil2_V1sh
Free mixers
Push the ENT key to recall the selection menu from the base display.
Select the desired menu with the selection buttons, then press the
ENT button again to recall the setting list of the menu.
Push the ESC key to stop the procedure.
Regardless of the type of model chosen, in each model memory are
available five linear mixers with the designation M1 to M5 as well as
four curve mixers with the designation C6 to C9.
Mixer setting step-by-step
1. Select the desired mixer.
2. Push the ENT key.
3. Set the mixer input "From" though the selection keys:
In a model memory of the type Airplane model, the control
functions 1 ... 4 are marked as follows.
CH1 Throttle/speed-brake control stick
AI Aileron control stick
EL Elevator control stick
RU Rudder control stick
And in the other model types so:
1 Throttle/pitch/throttle + brake control stick
2 Roll/direction control stick
3 Nick control stick
4 Tail control stick
"S" as switch channel
The letter "S" in the "from" column causes a constant input
signal to be fed to the mixer input. With a switch assigned to
this mixer, you can switch between two (still to be set) mixing
values.
Typ
from
zu
M5
C6
C7
??
??
??
??
C8
C9
??
??
??
??
??
??
–––
–––
–––
–––
–––
Typ
from
zu
M1
M2
M3
??
??
??
??
M4
M5
??
??
??
??
??
??
–––
–––
–––
–––
–––
Trainer
Fail-
Safe
General
setting
Free
Mixer
An-
nounce
Info
display
Model
memory
D/R
Expo
Tx
setting
Ctl
setting
Servo
setting
free
Mixer
M.Type
Phase
C1
curve
