Digital trim / Throttle switch-off trim
The two control sticks come with digital trimming. Briefly touch the
trimming switch to move the neutral position of the control stick by
a specific value with each click. If it is held, the trimming moves in
the corresponding direction with increasing speed.
The current trimming values are automatically saved when the
model memory is switched. In addition, the digital trimming func-
tions within a memory in specific relation to the phase (with the
exception of the trimming of the throttle/brake control stick (CH1).
In addition, the trimming of the throttle / brake control stick still has
a special "shut-off trim", which is intended for combustion engines:
If the trimming is a safe engine idle and from this position the trim-
ming in a one shot till the end of the trimming course in the "stop
motor" direction, then a further marking remains at the end position
in the display.
On the next commissioning of the model, simply press the trim once
in the "more throttle" direction to restore the trim to the last found
idle setting.
With the "Heli" model type, the CH1 trim in conjunction with the
"Throttle limiter function" has a further property: As long as the
throttle limiter is in the lower half of its setting range, CH1 trim acts
as an idle trim on the throttle servo connected to output 6.
The throttle trim works only on the throttle, not on the pitch servos.
Note also that the heli throttle servo must be connected to the out-
put 6 of the receiver.
GRAUBELE
#01
3:33h
Stop
Flight
K78
0:00
0:00
RX0.0V
5.2V
