• HD ("hold")
The last signals recognized as being correct are retained at the
output (hold).
• FS (fail safe)
The data of previously-saved fail safe positions are provided at
the output.
• OF (OFF)
No signals are supplied for the duration of the loss of reception.
Attention
Analogue servos and many digital servos no longer experience resis-
tance to the ongoing control pressure after control pulses stop and
are moved out of their position at greater or lesser speed.
Finally, switch the active field to channel selection by pushing
the ENT button at the bottom right. With the selection, you deter-
mine the highest control channels within the SUMD signal. Normally,
a value greater than "12" is not required by potentially connectable
devices.
SETTINGS & DISPLAYS sensor(s)
If one or more sensors are connected to a receiver and a telemetry
link exists with this receiver, you can retrieve the display of any sen-
sor and change its settings after the display "RX SERVO TEST"
described above.
On the last page of the receiver ("RX SERVOTEST"), in this case, a "
" pointing to the left should also be visible in the upper right-hand
corner of the left-hand pointing bracket " " as a sign that further
screens can be changed.
Switch between the modules step-by-step
1. Push simultaneously the left and the right selection keys.
The selection window shown on the left is displayed.
2. The desired line can be selected in a rotation order through the
upper and lower selection keys.
3. This selection can be confirmed immediately after pressing the
ENT key or simply waiting until the selection screen is automati-
cally blanked out after a short time.
Note
If you have connected at least one sensor to your telemetry
receiver and it has firmware from the same Vx firmware pack-
age as your receiver, you can switch directly between the indi-
vidual modules.
RX SERVO TESTV6.37
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
TEST : START
CH OUT TYPE:SUMDHD12
RX SERVO TESTV6.37
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
TEST : START
CH OUT TYPE:SUMDHD12
RX SERVO TESTV6.37
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
TEST : STOP
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
CH OUTPUT TYPE:ONCE
RECEIVER
etc.
VARIO
To Next Page
