Short-Cuts
The following key combinations can be used to call up certain menus
and options:
CLEAR
Simultaneous touch of the left and the right keys of the left four way
keypad will restore the active entry field's changed parameter value
back to its default value.
"Servo display"
Brief activation of the VIEW key of the right four-way keys will cause
a jump from the transmitter's base screen or from almost any menu
position to the "Servo display" menu, (Pushing the ESC key of the
right four-way keys you turn back to the related output point.)
"Telemetry" menu
Brief activation of the TLM key of the right four-way keys will cause
a jump from the transmitter's base screen or from almost any menu
position to the "Telemetry" menu, (Pushing the ESC key of the right
four-way keys you turn back to the related output point.)
Graphic display of "telemetry" data
Pressing any of the selection buttons switches from the basic display
to the "Telemetry data display" and from this display you can use the
upper or lower selection buttons to call up the list of selectable sen-
sors. Touching the ESC or ENT key will cause a return back to the base
screen.
"HIDDEN MODE"
Simultaneously pressing the left, right, and bottom selection buttons
of the left four-way keypad switches from the basic display of the
transmitter and from almost any menu position to the "Hidden
mode" menu, see manual Part 1.
Key lock
The four-way button fields and thus the access to any setting options
can be blocked against accidental actuation. Press the TLM and VIEW
buttons in the transmitter's base display for about one second. The
lock symbol appears in the display. Press the TLM and VIEW buttons
at the same time again for about two second to release the lock. The
lock symbol is open in the display.
