Make sure that the servos do not strike anything during the test rou-
tine.
TEST (Start/Stop)
In this line, the servo test integrated into the receiver is started and
stopped.
Servo test start step-by-step
1. Move to the line "TEST" by using the selection keys.
2. Push the ENT key.
The value field is displayed inverted:
3. Use one of the selection buttons to change the value field to
"START".
4. Push the ENT key.
The servo test starts and the entry field returns to normal.
Servo test stop step-by-step
1. Push the ENT key.
The value field is displayed inverted:
2. Use one of the selection buttons to change the value field to
"STOP".
3. Push the ENT key.
The servo test stops and the entry field returns to normal.
ALARM VOLT (receiver low voltage warning)
Through the "ALARM VOLT" the operating voltage of the receiver is
monitored. The alarm threshold is adjustable between 3,0 and 7,5
Volt in 0,1 Volt steps. When the set limit value is exceeded, an audi-
ble signal (interval-beep long / short) is produced, and in all "RX ..."
displays flashes "VOLT.E" in the upper right corner.
In the "RX DATAVIEW" display, the parameter "R-VOLT" is displayed
inverted.
ALARM TEMP +/- (receiver temperature monitoring)
These two options monitor the receiver temperature. You can pro-
gram a bottom threshold "ALARM TEMP-" (-20 … +10°C) and an
upper threshold "ALARM TEMP+" (+50 … +80°C). If the upper or
lower thresholds are exceeded, a continuous warning tone sounds,
and "TEMP.E" appears inverted at the top right in all receiver dis-
plays. On the display page "RX DATAVIEW", the parameter "R-TEM"
is also displayed inverted.
Make sure that the temperature of your receiver remains within the
permissible range under all operating conditions (ideally between
-10 and +55°C).
RX SERVO TESTV6.37
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
TEST : STOP
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
CH OUTPUT TYPE:ONCE
RX SERVO TESTV6.37
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
TEST : STOP
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
CH OUTPUT TYPE:ONCE
S–STR100% R–TEM.+28°C
L PACK TIME 00010msec
L.R-VOLT:03.5V
S–QUA100%S–dBM–030dBM
SENSOR1 :00.0V 00°C
SENSOR2 :00.0V 00°C
R-VOLT :03.7V
RX DATAVIEW VOLT.E
RX SERVO TESTV6.37
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
TEST : STOP
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
CH OUTPUT TYPE:ONCE
