93 / 116
S1002.PRO_mz12PRO_Teil2_V1sh
CH OUTPUT TYPE (connection type)
In this line, select the type of servo control or alternately the signal
type of the aggregate signal output.
ONCE
The servo connections of the receiver are actuated sequentially.
Recommended for analogue servos.
With this setting, the servos are automatically operated at a cycle of
in the line "PERIOD".
For the 12-channel receiver GR-24 (No. 33512) and the 16-channel
receiver GR-32 (No. 33516) the value is 30 ms.
SAME
The servo connections of the receiver are actuated simultaneously
in blocks. That is, the servos connected to connections 1 to 4 as well
as 5 to 8 can be simultaneously supplied with their control signals
with a GR-16 receiver (order No. 33508), and the servos connected
to connections 1 to 4, 5 to 8 as well as 9 to 12 can be simultaneously
supplied with their control signals with a GR-24 receiver (order No.
33512).
This is recommended for digital servos when several servos are used
for a single function (such as an aileron) so that the servos are fully
synchronized.
When exclusively digital servos are used, it is recommendable to set
"10 ms" in the line "PERIOD" of the display "RX SERVO" to exploit the
fast reaction of digital servos. When analogue servos or mixed oper-
ation is used, be sure to select "20 ms".
Attention
Selecting "SAME" always starts up to four servos at the same time,
it is essential to ensure that the receiver power supply is adequately
dimensioned.
SUMO (aggregate signal OUT)
A HoTT receiver configured as SUMO always generates an aggregate
signal from the control signals of all its controls channels, and for-
wards this to servo connection 8 of the GR-16 (No. 33508).
With receivers that have a two-digit number to the right of "SUMO"
in their display, the active field switches to the right to channel selec-
tion after "SUMO" is confirmed. With the selection, you determine
the highest control channels within the SUMO signal.
This presetting can be confirmed by pressing the ENT key again or by
pressing the selection keys of one of the other channels between 04
and 16 and pressing the ENT key.
RX SERVO TESTV6.37
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
TEST : START
CH OUT TYPE:ONCE
RX SERVO TESTV6.37
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
TEST : START
CH OUT TYPE:SAME
RX SERVO TESTV6.37
ALL–MIN : 1000µsec
ALL–MAX : 2000µsec
ALARM VOLT : 3.8V
ALARM TEMP–:–10°C
ALARM TEMP+: 55°C
TEST : START
CH OUT TYPE:SUMO 08
