79 / 116
S1002.PRO_mz12PRO_Teil2_V1sh
S-STR (signal strength)
The signal strength (S-STR) is displayed in percentage. In general, an
acoustic range warning (1 beep every second) is emitted once the
receiver signal in the feedback channel becomes too weak. Since the
transmitter's output is significantly higher than the receiver, the
model can always be operated safely. The model distance should
nevertheless be reduced for reasons of safety until the warning tone
stops.
R-TEM. (receiver temperature)
The receiver temperature threshold which triggers a warning can be
set in the submenu "RX SERVO TEST" under "ALARM TEMP+" (50 …
80°C) and "ALARM TEMP-" (-20 … +10°C). When the temperature is
too high or too low, a continuous warning tone sounds, and "TEMP.E"
appears in red at the top right in the receiver menu "RX". In the "RX
DATAVIEW" display, the parameter "R-VOLT" is displayed inverted.
The standard operating range is between -10 and +55 ° C.
L PACK TIME (data packages)
This indicates the longest period in milliseconds in which data pack-
ages are lost when transmitted from the transmitter to receiver. Only
when this period exceeds the "delay time" selected under "Fail-
Safe", the receiver falls into the fail-safe mode for the remaining
duration of the interference.
R-VOLT (actual receiver operating voltage)
Display of the current operating voltage of the receiver. This value is
also shown in the base display of the transmitter.
L.R-VOLT (lowest receiver operating voltage)
"L.R-VOLT" shows the lowest operating voltage of the receiver since
the last time the receiver was turned on.
If this voltage differs significantly from the current operating voltage
"R-VOLT", the drain on the receiver battery from the servos may be
too much and/or the resistance of the wiring is too high. In this case,
check and correct your power supply to maximize operating safety.
Sensors 1 + 2
Indicates the voltage and temperature in °C of the optional sensors
1 and 2.
6CH FUNCTION
Note
This function affects only receivers GR-12 and GR-16: Depending on
the status of these two receivers, the two previously described lines
"SENSOR 1 + 2" are replaced by the line "6CH FUNCTION".
