In normal model operation, the corresponding servo contrast-
ingly acts according to the set "MODE" in a malfunction.
DELAY (fail safe reaction time or delay)
This line specifies how long the receiver is going to keep the RC com-
ponents connected to it, after the connection has been terminated,
at their most recently received positions before forwarding the pre-
viously stored fail-safe positions to the connected components. This
setting is adopted by all the channels and only affects the servos pro-
grammed for "FAI(L) SAFE" mode.
The setting is carried out in steps of 0.25 s as described below under
"Programming step-by-step" under OUTPUT CH.
FAIL SAFE ALL (global fail safe setting)
This submenu allows you to set the fail-safe positions of RC compo-
nents with a "pushbutton" in a similarly simple way as the "Fail Safe"
menu of the transmitter mz-12 Pro HoTT:
Programming step-by-step
1. Move to the line "FAIL SAFE ALL" by using the selection keys.
2. Push the ENT key to activate the value field.
"NO" is displayed inverted:.
3. Use the upper or lower selection buttons to change the value field
to "SAVE".
Use the transmitter control elements to AT THE SAME TIME
move all the RC components, those that you have assigned in
the "MODE" "FAIL SAFE" line and/or the others which have to
take a specific position during the switch-on phase of the
receiver system, to the desired fail-safe position and keep
them still.
In the bottom "POSITION" line, the current servo position is
displayed for the selected OUTPUT CH.
4. Push the ENT key.
The display in the value field changes again from "SAVE" to
"NO".
This saves the positions of all of the RC components affected
by these measures and simultaneously transfers them to the
"F.S.Pos." line so that the receiver can access them in a mal-
function.
5. You can now release the control elements of the transmitter.
6. Carefully switch off the transmitter and check the fail-safe posi-
tions on the basis of the servo positions.
7. Eventually repeat the process.
RX FAIL SAFE V6.37
INPUT CH: 01
MODE : FAI-SAFE
F.S.POS. : 1500µsec
DELAY : 0.75sec
OUTPUT CH: 01
POSITION : 1670µsec
FAIL SAFE ALL: SAVE
