MIDI Implementation
Channel Voice Message
Note Off
Status 2nd Byte 3rd Byte
8nH kkH vvH, or
9nH kkH 00H
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
kk=Note Number: 00H - 7FH (0 - 127)
vv=Velocity(disregard): 00H - 7FH (0 - 127)
Note On
Status 2nd Byte 3rd Byte
9nH kkH vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
kk=Note Number: 00H - 7FH (0 - 127)
vv=Velocity: 00H - 7FH (0 - 127)
Control Change
Bank Select (CC#0, 32)
Status 2nd Byte 3rd Byte
BnH 00H mmH
BnH 20H llH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
mm,ll=Bank Number: 00H 00H = User
01H 00H = Preset
64H 00H - 6DH 00H= Bank [1] to [10]
Until you send the Program Change, the Bank Select process is reserved.
Expression (CC#11)
Status 2nd Byte 3rd Byte
BnH 0BH vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Expression: 00H - 7FH (0 - 127)
Spring Shock (CC#48)
Status 2nd Byte 3rd Byte
BnH 30H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Velocity: 00H - 7FH (0 - 127)
Glide (CC#49)
Status 2nd Byte 3rd Byte
BnH 31H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H - 7FH (0 - 127)
0 - 63=Off, 64 - 127=On
Damper (CC#64)
Status 2nd Byte 3rd Byte
BnH 40H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H - 7FH (0 - 127)
0 - 63=Off, 64 - 127=On
ProChord Active (CC#84)
Status 2nd Byte 3rd Byte
BnH 54H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H - 7FH (0 - 127)
0 - 63=Off, 64 - 127=On
Activates “Harmony” parts for Organ section during this parameter is “On”.
Drawbar Priority (CC#85, 86)
Status 2nd Byte 3rd Byte
BnH 5kH vvH
k=Drawbar Group: 5 = Upper, 6=Lower
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H - 7FH (0 - 127)
0 - 63=Off, 64 - 127=On
Leslie Fast (CC#92)
Status 2nd Byte 3rd Byte
BnH 5CH vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H - 7FH (0 - 127)
0 - 63=Off, 64 - 127=On
This control change is only for receive.
NRPN MSB/LSB (CC#98, 99)
Status 2nd Byte 3rd Byte
BnH 63H mmH
BnH 62H llH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
mm=upper byte of the parameter number specified by NRPN
ll=lower byte of the parameter number specified by NRPN
Data Entry (CC#6, 38)
Status 2nd Byte 3rd Byte
BnH 06H mmH
BnH 26H llH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
mm,ll=the value of the parameter specified by NRPN
Program Change
Status 2nd Byte
CnH ppH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
pp=Program Number: 00H - 63H = Patch #0 to 99
64H - 6DH = Favo. Number [1] to [10]
7FH = [Manual]
Example of operation
ex: select Patch P016
Bx 00 01 Bx 20 00 Cx 0F (x=Upper Channel)
ex: select Favorite Bank[2], Number[6]
Bx 00 65 Bx 20 00 Cx 69 (x=Upper Channel)
ex: select Manual
Cx 7F (x=Upper Channel)
Channel Mode Message
All Sounds Off (CC#120)
Status 2nd Byte 3rd Byte
BnH 78H 00H
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
When this message is received, all currently-sounding notes on the correspond-
ing channel will be turned off immediately.
Reset All Controllers (CC#121)
Status 2nd Byte 3rd Byte
BnH 79H 00H
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
When this message is received, the following controllers will be set to their reset
values.
Expression: 127
Glide: 0
Damper: 0
NRPN: unset; previously set data will not change
All Notes Off (CC#123)
Status 2nd Byte 3rd Byte
BnH 7BH 00H
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
When All Notes Off is received, all notes on the corresponding channel will be
turned off. However if Hold 1 or Sostenuto is ON, the sound will be continued
until these are turned off.
