Hammond SKX User Manual


Skx
Owner’s Manual
144
Patch Parameters
MIDI INFORMATION - continued
Category Parameter NRPN SysEx Address SysEx
Length
Data Patch Load
LSB
(62)
MSB
(63)
MSB to LSB
Name
15 Characters
-- -- 01 00 00 0F
7 bit ASCII always
Internal Zone
Manual Bass
07 00 00 07 00 01
00, 01 (O /On) INT
Manual Bass Mode
07 01 00 07 01 01
00 - 02 (Lower, Chord, Poly)
Manual Bass Range Hi
07 02 00 07 02 01
24 - 60 (MIDI note number)
Great To Pedal
07 03 00 07 03 01
00, 01 (O /On)
G to P Range Hi
07 04 00 07 04 01
24 - 3C (MIDI note number)
Split
07 05 00 07 05 01
00, 01 (O /On)
Split Point
07 06 00 07 06 01
24 - 60 (MIDI note number)
Key Octave Upper 1
07 07 00 07 07 01
3E - 40 - 42 (-2 - 0 - +2)
Key Octave Lower 1
07 08 00 07 08 01
3E - 40 - 42 (-2 - 0 - +2)
Glide Length
07 09 00 07 09 01
00 - 18 (0 - 24 semitones)
Glide Time Attack
07 0A 00 07 0A 01
00 - 31 (0.1 - 5.0 seconds)
Glide Time Release
07 0B 00 07 0B 01
00 - 31 (0.1 - 5.0 seconds)
Glide Amp
07 0C 00 07 0C 01
00, 01 (O /On)
Glide On Org
07 0D 00 07 0D 01
00, 01 (O /On)
Glide On EXV1
07 0E 00 07 0E 01
00, 01 (O /On)
Glide On EXV2
07 0F 00 07 0F 01
00, 01 (O /On)
Key Octave Upper 2
07 10 00 07 10 01
3E - 40 - 42 (-2 - 0 - +2)
Key Octave Lower 2
07 11 00 07 11 01
3E - 40 - 42 (-2 - 0 - +2)
External Zone
MIDI Channel
4n 00 00 4n 00 01
00 - 0F (1 - 16) EXT
Switch
4n 01 00 4n 01 01
00, 01 (O /On)
Allocate
4n 02 00 4n 02 01
00 - 03
00: O
01: Upper
02: Lower
03: Pedal
Key Range Lo
4n 03 00 4n 03 01
00 - 7F (MIDI note number)
Key Range Hi
4n 04 00 4n 04 01
00 - 7F (MIDI note number)
Bank Select MSB
4n 05 00 4n 05 01
00 - 7F
Bank Select LSB
4n 06 00 4n 06 01
00 - 7F
Program Change
4n 07 00 4n 07 01
00 - 7F
Octave Shift
4n 08 00 4n 08 01
3E - 40 - 42 (-2 - 0 - +2)
Volume
4n 09 00 4n 09 01
00 - 7F
Pan
4n 0A 00 4n 0A 01
00 - 40 - 7F (L64 - C - R63)
Velocity
4n 0B 00 4n 0B 01
00 - 04 (O , Normal - Easy)
Expression Minimum
4n 0C 00 4n 0C 01
00 - 3F (0 - 63)
Expression Maximum
4n 0D 00 4n 0D 01
40 - 7F (64 - 127)
Expression CC#
4n 0E 00 4n 0E 01
00, 01 (7, 11)
Tx. Damper On
4n 0F 00 4n 0F 01
00, 01 (O /On)
Extra Voice
Switch Upper
5n 00 00 50 00 01
00, 01 (O /On) EXV
Switch Lower
5n 01 00 50 01 01
00, 01 (O /On)
Octave Shift
5n 03 00 50 03 01
3E - 40 - 42 (-2 - 0 - +2)
Key Range Lo
5n 04 00 50 04 01
00 - 7F (MIDI note number)
Key Range Hi
5n 05 00 50 05 01
00 - 7F (MIDI note number)
Inst. Group
5n 06 00 50 06 01
00 - 06 (1 - 7)
Inst. Number
5n 07 00 50 07 01
00 - 7F (1 - 128)
Volume
50 08 00 50 08 01
00 - 7F (0 - 127)
Balance
51 08 00 50 08 01
00 - 40 - 7F
(64:0 - Even - 0:63)
Velocity
5n 09 00 50 09 01
00 - 04 (O , Normal - Easy)
Expression
50 0A 00 50 0A 01
00, 01 (O /On)
Example “n” means Zone number. 1=0, 2=1, 3=2
Turn Extra Voice On via NRPN ...........................Bx 62 50 63 00 06 01 (x = Upper channel)
Turn Extra Voice On via System Exclusive ............F0 55 dd 10 23 13 00 50 00 01 F7 (dd = Device ID)

Hammond SKX Specifications

General

Manuals	2
Drawbars	9 per manual
Power Supply	AC Adapter
Effects	Chorus, Vibrato, Reverb
Connectivity	USB, MIDI, Audio Out, Headphones, Expression Pedal
Keyboard	61 keys (waterfall style)
Piano/Ensemble Section	Pianos, Strings, Brass
Display	LCD
Touch Sensitivity	Adjustable
