Owner’s Manual
148
Leslie Parameters
MIDI INFORMATION - continued
System Parameters
Category Parameter Data Range Default Value
MIDI
MIDI IN Lower, Pedal, Low+Ped,
Sequence, Upper, Upp+Ped
Pedal
Local Control O /On On
TRx. NRPN O /On On
Tx. Leslie Param. SK/21 SK
Rx. Dump O /On On
TRx. Prog. Change O /On On
TRx. Drawbar Regi. O /On On
Tx. Ext. Zone O /On O
TRx. Channel Upper 1 - 16, O 1
TRx. Channel Lower 1 - 16, O 2
TRx. Channel Pedal 1 - 16, O 3
Device ID 1 - 32 1
Music Player
Chain All, One, Shu e All
Keyboard
Velocity O set -32 - +32 0
Sounding Point Deep / Auto Deep
Transpose
Act Organ Every / Next Next
Act Extra Voice Every / Next Next
Section
Part On Mode Additive / Alternate Additive
Audio
Output Stereo / Mono Stereo
Power
Auto O Disable / 30min 30min
Ext. Leslie
Channel(s) 1, 3 3
Category Parameter NRPN (SK) NRPN (21) SysEx Address SysEx
Length
Data
LSB
(62)
MSB
(63)
LSB
(62)
MSB
(63)
MSB to LSB
Cabinet
Name
-- -- -- -- 03 00 00 0A
(10 Characters)
Slow Speed Horn
06 00 7F 00 00 06 00 01
Slow Speed Bass
06 01 7F 01 00 06 01 01
Fast Speed Horn
06 02 7F 02 00 06 02 01
Fast Speed Bass
06 03 7F 03 00 06 03 01
Rise Time Horn
06 04 7F 04 00 06 04 01
Rise Time Bass
06 05 7F 05 00 06 05 01
Fall Time Horn
06 06 7F 06 00 06 06 01
Fall Time Bass
06 07 7F 07 00 06 07 01
Brake Time Horn
06 08 7F 08 00 06 08 01
Brake Time Bass
06 09 7F 09 00 06 09 01
Level Horn
06 0A -- -- 00 06 0A 01
Level Bass
06 0B -- -- 00 06 0B 01
Mic. Angle
06 0C 7F 0A 00 06 0C 01
Mic. Distance
06 0D 7F 0B 00 06 0D 01
Horn Character
06 0E 7F 0D 00 06 0E 01
Ampli er
06 0F -- -- 00 06 0F 01
Speaker
06 10 -- -- 00 06 10 01
NRPN SK/21 is switched automatically by Leslie speaker is disconnected/connected.
Category Parameter Data Range
Tone Wheel
Name (10 characters)
Level -20 - +2 [dB]
HPF Cut O Freq. 0 - 127
LPF Cut O Freq. 0 - 127
LPF Resonance -100 - +100
Category Parameter Data Range
Pipe
Volume 0 - 127
Detune -50 - +50
Chi O , Soft, Mid, Loud
Cut O Freq. -64 - +0
Pan - Direction L64 - C - R63
Pan - Imaging Fixed, L-R, R-L, Pyramid,
Inverted Pyramid
Tone Wheel Parameters Pipe Parameters
