Hammond SKX User Manual

147
Appendix
Category Parameter NRPN SysEx Address SysEx
Length
Data Preset Load
LSB
(62)
MSB
(63)
MSB to LSB
E ects
Overdrive On
3p 00 00 3p 00 01
00, 01 (O /On) EFFECT
p=0: DRAWB
p=1: EXV
Overdrive Type
3p 01 00 3p 01 01
00 - 03
00: Tube
01: Stomp Box
02: Clip
03: E. Pf. Amp
Overdrive Drive Level
3p 02 00 3p 02 01
00 - 7F
Overdrive Controlled Exp.
3p 03 00 3p 03 01
00-03
00: EX-OD
01: OD-EX
02: OD Only
03: Input
Multi E ect On
3p 04 00 3p 04 01
00, 01 (O /On)
Multi E ect Type
3p 05 00 3p 05 01
00-07
00: Tremolo
01: Auto Pan
02: Wah-Wah
03: Ring Mod.
04: Phaser
05: Flanger
06: Chorus
07: Delay
Multi E ect Parameter 0
3p 06 00 3p 06 01
00-03
Multi E ect Parameter 1
3p 07 00 3p 07 01
00-03
Multi E ect Parameter 2
3p 08 00 3p 08 01
00-7F
Multi E ect Parameter 3
3p 09 00 3p 09 01
00-7F
Multi E ect Parameter 4
3p 0A 00 3p 0A 01
00-7F
Multi E ect Parameter 5
3p 0B 00 3p 0B 01
00-7F
Multi E ect Parameter 6
3p 0C 00 3p 0C 01
00-7F
Multi E ect Parameter 7
3p 0D 00 3p 0D 01
00-7F
EQ Bass Gain
3p 0E 00 3p 0E 01
00 - 09 - 12 (-9 - 0 - +9)
EQ Bass Frequency
3p 0F 00 3p 0F 01
00 - 0A (20 - 200Hz)
EQ Mid Gain
3p 10 00 3p 10 01
00 - 09 - 12 (-9 - 0 - +9)
EQ Mid Frequency
3p 11 00 3p 11 01
00 - 0A (250 - 3.1kHz)
EQ Treble Gain
3p 12 00 3p 12 01
00 - 09 - 12 (-9 - 0 - +9)
EQ Treble Frequency
3p 13 00 3p 13 01
00 - 03 (4.0 - 8.0 kHz)
EQ Tone Control
30 14 00 3p 14 01
00 - 09 - 12 (-9 - 0 - +9)
OD Output Level
3p 15 00 3p 15 01
00 - 7F (0 - 127)
Reverb On
0A 00 00 0A 00 01
00, 01 (O /On) REV
Reverb Type
0A 01 00 0A 01 01
00 - 0A
00: Room 1
01: Room 2
02: Live House
03: Hall 1
04: Hall 2
05: Church
06: Plate
07: Spring
08: Delay
09: Panning Delay
0A: Reverb + Delay
Reverb Level
0A 02 00 0A 02 01
00 - 7F (0 - 127)
Reverb Time
0A 03 00 0A 03 01
00 - 7F (0 - 127)
Reverb Delay Feedback
0A 04 00 0A 04 01
00 - 1F (0 - 96%)
Reverb Delay Time
0A 05 00 0A 05 01
00 - 44 (4.7 - 2000ms)
Example: “p” means Section number. Organ=0, Extra Voice=1
Set Multi-E ect EXV at Phaser via NRPN ...........Bx 63 05 62 31 06 04 26 00 (x = Upper channel)
Set Multi-E ect EXV at Phaser via SysEx .............F0 55 dd 10 23 13 00 31 05 04 F7 (dd = Device ID)

Hammond SKX Specifications

General

Manuals	2
Drawbars	9 per manual
Power Supply	AC Adapter
Effects	Chorus, Vibrato, Reverb
Connectivity	USB, MIDI, Audio Out, Headphones, Expression Pedal
Keyboard	61 keys (waterfall style)
Piano/Ensemble Section	Pianos, Strings, Brass
Display	LCD
Touch Sensitivity	Adjustable
