Hammond SKX - Sound Engine Structure


Skx
Owner’s Manual
36
SOUND ENGINE STRUCTURE
Reverb
Line Out,
Phones
Leslie 11Pin,
without Leslie simulator
TC & Equalizer
Master
Equalizer
Equalizer
Organ Volume
EXV Volume
EXV Balance
12
Extra Voice
Generator #2
Extra Voice
Generator #1
Vibrato & Chorus
Overdrive
Overdrive
Lower&Upper
Virtual
Tone Wheel Set
Pedal
Virtual
Tone Wheel Set
Pedal
Drawbars
Lower
Drawbars
Upper
Drawbars
Percussion
Pedalboard
Lower Keyboard
Upper Keyboard
Multi Effect
Multi Effect
Expression
Expression
Pedal
V&C
Allocate
Lower
Upper
Lower
Upper
from keyboards
Leslie
Simulator
