Hammond SKX - VIB&CHO (Vibrato & Chorus)

81
Setting the Parameters
VIB&CHO ( Vibrato & Chorus)
In this mode, the settings speci c to Vibrato and Chorus are adjusted.
To locate this mode:
❶ MODE
Sets the Mode of the Vibrato and Chorus e ect.
V1 (C1): light vibrato (chorus)
V2 (C2): vibrato (chorus) of standard depth.
V3 (C3): deepest vibrato (chorus)
“Chorus” makes richness to the sound with blending direct and
vibrato tone.
This Mode can be selected on the top panel by holding each
[VIBRATO & CHORUS] button and press [V1] to [C3]button
(right  gure).
❷ RATE
Sets the Speed of the Vibrato and Chorus e ect.
 e setting range is 6.10 - 7.25 Hz.
❸ VIBRATO - TREMOLO
Sets Tremolo (amplitude modulation) of the Vibrato and Chorus
e ect.
 e setting range is 0 - 15.
❹ EMPHASIS
Sets Emphasis (high frequency boost) of the Chorus e ect (C1 / C2 / C3).
 e setting range is 0 - 9 dB.
❺ MIX
Sets Mixing ratio of the Chorus e ect (C1 / C2 / C3).
 e setting range is D64 (only the Direct tone, no vibrato tone) - EVEN - 63V (only
the Vibrato tone, no direct tone).
❻ PEDAL
Sets Vibrato and Chorus a ects on the Pedal part by [LOWER] button.
 e setting range is ON/OFF.
❼ DEPTH V1,❽ DEPTH V2, ❾ DEPTH V3, ❿ DEPTH C1, ⓫ DEPTH C2,⓬ DEPTH C3
Sets the Depth of each Vibrato and Chorus e ect mode.
 e setting range is 0 - 15.
or, keep pressing either of the VIBRATO & CHORUS [UPPER], [LOWER]
buttons for a few seconds.
See “Function mode” (P. 66) for operation details.
MENU/
EXIT
ENTER
NOTE: All the parameters in these modes are
Patch Parameters. They are recorded
into the Patch.
PEDAL
On the vintage B-3/C-3, the Vibrato and Chorus
a ects not only LOWER part but also PEDAL part
via [LOWER] (exactly, “GREAT”) tablet by the circuit
structure. It is divided on later models.
This parameter simulates that.
Setting the Vibrato & Chorus Mode
❶
❶
❷
❷
❸
❸
❹
❹
❺
❺
❻
❻
❼
❼
❽
❽
❾
❾
❿
❿
⓫
⓫
⓬
⓬
Press
With holding
