ACQUISITION AND STORAGE
ACQUISITION AND STORAGE
9
B Choose the type of Acquisition Mode (see Fig. 9.8)
Fig. 9.8 Start of data recording to drive
C Specify the pre- and post-trigger times (in case triggers are used) (see Fig. 9.9)
Fig. 9.9 Pre- and post-trigger duration
D Highsamplerateandthereducedsampleratepergroupcanbedened.Inthis
area it should also be indicated which data is to be stored (see Fig. 9.10)
Fig. 9.10 Storage and timebase
