Voltage Channel - Safe and unsafe connections
InthefollowingguresisshownhowaGN310B/GN311Bpowercardhastobe
connected. Safe connection (see Fig. 12.23), unsafe connections (see Fig. 12.24 and
Fig. 12.25).
Make sure the cable connectors are put COMPLETELY into the input of the GN310B/
GN311B power card.
Fig. 12.23 GN310B/GN311B Power card - safe connection
Do not leave one of the connectors unconnected per differential pair.
Fig. 12.24 GN310B/GN311B Power card - unsafe connection (1)
