HBK GEN7iB GEN Series User Manual

GEN7iB
241
INPUT CARDS
INPUT CARDS
12
The input channels of the GN816 and GN816 are isolated. This means that the input
channelandamplierarefullyisolatedfrom(earth)ground.Inthiscontext,fully
isolated means a very high resistance and a very small capacitive coupling to ground.
This is for safety and to avoid ground loops.
Characteristics per channel:
● The input BNC connector is isolated from the system ground.
● The isolated ground is externally accessible, as shown in Fig. 12.58.
н
Ͳ
ϵϬϬŬɏ
ϭϬϬŬɏ
h
ŝƐŽ
h
Ěŝī

/E;нͿ
/E;ͲͿ
/ƐŽůĂƚĞĚ
ĐŚĂŶŶĞů
EŽŶͲŝƐŽůĂƚĞĚ
ƐLJƐƚĞŵ
^ŝŶŐůĞͲĞŶĚĞĚŝƐŽůĂƚĞĚ

Fig. 12.58 Single-ended isolated input channel
Using probes:
It is possible to use passive voltage probes with single-ended isolated inputs.
Using a standard passive 10:1 probe in combination with the GN815 and GN816 results
in the situation shown in Fig. 12.59.
н
Ͳ
ϵϬϬŬɏ
ϭϬϬŬɏ
h
ŝƐŽ
h
Ěŝī
/E;нͿ
/E;ͲͿ
/ƐŽůĂƚĞĚ
ĐŚĂŶŶĞů
EŽŶͲŝƐŽůĂƚĞĚ
ƐLJƐƚĞŵ
^ŝŶŐůĞͲĞŶĚĞĚŝƐŽůĂƚĞĚ

ϵDɏ
ϭϬΎh
Ěŝī
WĂƐƐŝǀĞƉƌŽďĞ
Fig. 12.59 Input channel with a standard 10:1 passive probe
Using a high voltage passive 10:1 probe in combination with the GN815 and GN816
results in the situation shown in Fig. 12.60. The voltage division is done externally in
the probe to maintain accuracy.
