GEN7iB
94
SETTING UP THE GEN7iB
SETTING UP THE GEN7iB
7
Set the trimmer of the probe so that the signal in Perception resembles the input
signal.
Fig. 7.13 below shows how the signal should look. When the trimmer is positioned
incorrectly, undershoot or overshoot is seen in the signal.
$
% &
Fig. 7.13 Trimming of response - Incorrect and correct waveform responses
A Incorrect - Undershoot
B Correct
C Incorrect - Overshoot
