137
_____________________________________________________________________________________________
9.4 Command
______________________________________________________________________________________________
Syntax
:CONF:WITH:RANG <data>
<data>
2.5, 5.0 (NR2)
Response
syntax
OK
Function
Sets the voltage range for withstand voltage tests, in the READY state.
Example
Sets the voltage range for withstand voltage tests.
Transmission >:CONF:WITH:RANG 2.5
The withstand voltage test voltage range is set to 2.5 kV.
Response OK
Settings completion
Error
The execution of this command in a state other than the READY state causes an execution error.
Syntax
:CONF:WITH:RANG?
Response
syntax
<data>
<data>
2.5, 5.0 (NR2)
Function
Queries the voltage range for withstand voltage tests.
Example
Queries the voltage range for withstand voltage tests.
Transmission :CONF:WITH:RANG?
Queries the withstand voltage test voltage range.
Response 2.5
The voltage range is 2.5 kV.
Syntax
:CONF:WITH?
Response
syntax
<data>
<data>
Withstand voltage test comparativevoltage value: 0.00 to 5.00 (NR2)
Upper-limit value : 0.1 to 120 (NR1 or NR2)
Lower-limit value : 0.1 to 119 (NR1 or NR2)
Test time value : 0.5 to 999 (NR1 or NR2)
Voltage range : 2.5 or 5.0 (NR2)
Function
Queries the withstand voltage test settings.
Example
Queries the withstand voltage test settings.
Transmission :CONF:WITH?
Queries the withstand voltage test settings.
Response 1.50,5.0,0.1,30.0,2.5
Comparative voltage: 1.50 kV, Upper-limit value: 5 mA,
Lower-limit value: 0.1 mA, Test time value: 30.0 s, Voltage range: 2.5 kV
:CONF:WITH:RANG
Sets the voltage range for withstand voltage tests.
:CONF:WITH:RANG?
Queries the voltage range for withstand voltage tests.
:CONF:WITH?
Queries the withstand voltage test settings.
