Hioki 3159 - Page 154

142
_____________________________________________________________________________________________
9.4 Command
______________________________________________________________________________________________
Syntax
:STAT?
Response
syntax
<data>
<data> WPASS
: Withstand voltage mode PASS
IPASS
: Insulation resistance mode PASS
WUFAIL
: Withstand voltage mode UPPER FAIL
IUFAIL
: Insulation resistance mode UPPER FAIL
WLFAIL
: Withstand voltage mode LOWER FAIL
ILFAIL
: Insulation resistance mode LOWER FAIL
WREADY
: Withstand voltage mode READY
IREADY
: Insulation resistance mode READY
WTEST
: Withstand voltage mode TEST
ITEST
: Insulation resistance mode TEST
WULFAIL
: Withstand voltage mode FAIL
NULL
: Others
Function
Queries the state.
Example
Queries the state.
Transmission :STAT?
Queries the state.
Response WREADY
In the withstand voltage mode READY state.
Syntax
:MODE <data>
<data> MWITH
: Withstand voltage mode
MINS
: Insulation resistance mode
AWI
: Withstand voltage test
insulation resistance test
AIW
: Insulation resistance test
withstand voltage test
Response
syntax
OK
Function
In the READY state, sets the test mode.
Example
Sets the test mode.
Transmission :MODE AWI
Sets the test mode: withstand voltage test
insulation resistance test.
Response OK
Settings completion
Error
The execution of this command in a state other than the READY state causes an execution error.
Note that an execution error occurs when auto test mode is selected with test time set off in
withstand voltage mode or insulation resistance test mode.
:STAT?
Queries the state.
:MODE
Sets the test mode.
