9.4 Command
______________________________________________________________________________________________
Syntax
:MODE?
Response
syntax
<data>
<data> MWITH
: Withstand voltage mode
MINS
: Insulation resistance mode
AWI
: Withstand voltage test
insulation resistance test
AIW
: Insulation resistance test
withstand voltage test
Function
Queries the test mode.
Example
Queries the test mode.
Transmission :MODE?
Queries the test mode.
Response AWI
Test mode: withstand voltage
test insulation resistance test
Syntax
:MEAS:RES:WITH?
Response
syntax
<data>
<data>
Measured voltage value, measured current value, test time elapsed determination.
Excluding determination : NR2
Determination : PASS, UFAIL, LFAIL, ULFAIL, OFF (See Section 9.5)
Function
Queries the results of the preceding test. Returns the screening results and valid values at
termination of the preceding test. The test results are updated upon termination of a new test.
Example
Queries the measured value.
Transmission :MEAS:RES:WITH?
Queries the withstand voltage test results.
Response 1.50,2.00,30.0,PASS
Measured voltage value: 1.50 kV; Measured current value: 2.00 mA;
Test time elapsed: 30.0 s; Determination: PASS
Syntax
:MEAS:WITH:VOLT?
Response
syntax
<data>
<data>
Withstand voltage test measured voltage value (NR2)
Function
Queries the measured voltage value for withstand voltage tests.
Example
Queries the measured voltage value for withstand voltage tests.
Transmission :MEAS:WITH:VOLT?
Queries the measured voltage value for withstand voltage tests.
Response 1.50
The measured voltage value is 1.50 kV.
:MODE?
Queries the test mode.
:MEAS:RES:WITH?
Queries the withstand voltage test result.
:MEAS:WITH:VOLT?
Queries the measured voltage value for withstand voltage tests.
