Hioki 3159 - Current Detection Section; Decision Function

144
_____________________________________________________________________________________________
9.4 Command
______________________________________________________________________________________________
Syntax
:MEAS:WITH:CURR?
Response
syntax
<data>
<data>
Withstand voltage test measured current value (NR1 or NR2)
Function
Queries the measured current value for withstand voltage tests.
Example
Queries the measured current value for withstand voltage tests.
Transmission :MEAS:WITH:CURR?
Queries the measured current value for withstand voltage tests.
Response 2.00
The measured current value is 2.00 mA.
Syntax
:MEAS:WITH:TIM?
Response
syntax
<data>
<data>
Withstand voltage test time elapsed (NR1 or NR2)
Function
Queries the test time elapsed for withstand voltage tests.
Example
Queries the test time elapsed for withstand voltage tests.
Transmission :MEAS:WITH:TIM?
Queries the test time elapsed for withstand voltage tests.
Response 30.0
The test time elapsed is 30.0 s.
Syntax
:MEAS:RES:INS?
Response
syntax
<data>
<data>
Measured voltage value, measured resistance value, test time elapsed determination.
Excluding determination : NR1 or NR2
Determination : PASS, UFAIL, LFAIL, ULFAIL, OFF
Function
Queries the results of the preceding test. Returns the screening results and valid values at
termination of the preceding test. The test results are updated upon termination of a new test.
Example
Queries the measured value.
Transmission :MEAS:RES:INS?
Queries the insulation resistance test result.
Response 510,100,10.0,PASS
Measured voltage value: 510 V; Measured current value: 100 MΩ;
Test time elapsed: 10.0 s; Determination: PASS
:MEAS:WITH:CURR?
Queries the measured current value for withstand voltage tests.
:MEAS:WITH:TIM?
Queries the test time elapsed for withstand voltage tests.
:MEAS:RES:INS?
Queries the insulation resistance test result.
