Hitachi P-N23NA2 Service Manual

2 Unit installation
Optional accessories
SMGB0099 rev.0 - 12/2016
92
2.13.6.2 For RCD-FSN3E indoor units: F-90MD-K1 and F-160MD-K1 (Antibacterial long life
air lter)
352
a
40
40
P
68
49
60
417
300
8
630
10
Indoor unit
Antibacterial
long life air lter
Filter box (option)
Ceiling
Air panel
Long life air lter
Attached with
optional Air panel
Air inlet
at grille
Filter holder (*1)
Installation
height
Min.
Paper
frame
Filter
media
Model/Air ow direction
Air
? NOTE
*1) Insert the antibacterial long life air lter into the lter box, the x it with the
lter holder
Air ow chart
Applicable Indoor unit RCD-(0.8-3.0)FSN3 RCD-(4.0-6.0)FSN3
2010 30 400
20
40
B:F-160MD-K1
A:F-90MD-K1
A
B
Air volume (m
3
/min)
Pressure Loss (Pa)
Dust collection efciency % 65 (Gravimetric method (*1))
Air ow m
3
/min. 19.5 32.5
Initial pressure Loss Pa (mmAq) 17.0 20.5
End pressure Loss Pa (mmAq) 55.9 62.8
Colour (Filter/frame) White / Brown
Life period 8 years (with 2500 hours maintenance)
Cleaning Not available
Accessory Installation manual
Weight kg 0.9 0.8 x 2
Performance
Avoids the multiplication of
bacteria and mould
Filter material Antibacterial bre Synthetic bre Non-woven fabric
2.13.7 Deodorising lter
2.13.7.1 For RCI-FSN4 indoor units: F-71L-D1 and F-160L-D1
The dimensions of the deodorising lter are indicated in the following gure.
Remember that the lter thickness depends on the model.
588
544
588
544
AIR FLOW
F-160L-D1
a
2 pieces
(reinforcement)
Model
Filter
Aluminium
frame
Air
Air ow direction
Model
Dimension F-71L-D1 F-160L-D1
a 25 45
