11 Maintenance notes
Indoor cleaning
SMGB0099 rev.0 - 12/2016
359
11
Dry the remains of any water on the indoor unit.
Check the insulation of the drain pump using a megohmmeter. Check that the insulation is above 1 MΩ when 500V are
applied.
Connect the wiring.
Perform the neutralisation treatment after cleaning.
After cleaning, t the drain pan by lowering the rope.
Perform the neutralisation treatment after cleaning.
11.2.4 Cleaning the oor console and oor concealed console indoor unit RPF(I)
Remove the front panel in line with the instructions given in chapter “9.10.4 Removal of the front panel”.
Drain pan
Front side
partition
Heat exchanger
Cover the heat
exchanger with
vinyl sheet
Remove any dust from the heat exchanger.
Remove the dust from the heat exchanger by brushing it in a downwards direction. Collect all of the dust in a bucket or a
cardboard box.
Bucket
