Hitachi P-N23NA2 Service Manual

6 Optional functions
Optional functions through Remote control
SMGB0099 rev.0 - 12/2016
209
6
6.2 Optional functions through Remote control
The next list refers to the optional functions available to indoor units from the remote control switch. Note that not all
remote control switch have access to all the optional functions. Check the Technical Catalogue for Indoor units remote
controls.
6.2.1 List of optional remote control functions. (PC-ARFPE)
Elem. Optional function
Individual
setting
Settings Setting conditions Description
b1
Correction of setting
temperature in heating
Models:
RCD-FSN3
RCIM-FSN4(E)
O
00
Normal (Setting Temperature +
4ºC)
This function is used to adjust the
difference of temperature between
the setting temperature of the remote
control switch and the inlet air
temperature of the indoor unit.
This is useful when the inlet air
thermistor is not placed inside the
indoor unit.
01 Release (Setting Temperature)
02 Setting Temperature + 2ºC
03 Setting Temperature + 3ºC
04 Setting Temperature + 1ºC
Correction of setting
temperature in heating
Models:
RPI-FSN3(P)E
RPC-FSN3E
RPF(I)-FSN2E
RPI-FSN4E
RPIM-FSN4E(-DU)
O
00
Normal (Setting Temperature
+ 4ºC or Setting temperature +
2ºC)
Standard setting. It increases the
temperature +4ºC
01
Release (Setting Temperature)
Removal
02
Setting Temperature + 2ºC
Increases the temperature +2ºC
(1)
.
Correction of setting
temperature in heating
Models:
RCI-FSN4
RPC-FSN3
RPK-FSN3M
O
00
Normal (Setting Temperature +
4ºC
Standard setting. Increases the
temperature +4ºC
01
Release (Setting Temperature)
Removal
02
Setting Temperature + 2ºC
It increases the temperature
+2ºC
(1)
.
b2
Circulator function at
heating Thermo-OFF
O
00 Not activated function
This function means that the fan
unit remains running after the air
conditioning system has stopped
to prevent the air in the room from
stratifying.
01 Activated function
b3
Forced compressor
operation for at least
three minutes through C7
setting
O
00
Not activated function
(C7 setting possible)
This function is used to allow
the setting of C7: protect the
compressor, preventing it from being
started or stopped for periods of less
than three minutes.
Not available for models:
RCIM-FSN4(E)
RCD-FSN3
01
Activated function
(C7 setting not possible)
b4
Change the lter cleaning
period.
O
00 Standard (1200 h factory setting)
This function is used to modify the
period during which the remote
control indicates the air lter
replacement.
01 100 hours
02 1200 hours
03 2500 hours
04 No indication
b5 Fixing of operation mode X
00 Not activated function Once the unit operating mode has
been selected, this function prevents
it from being modied from the
remote control.
01 Activated function
b6
Fixing of setting
temperature
X
00 Not activated function
Once the unit temperature has been
selected, this function prevents from
being modied from the remote
control.
01 Activated function
