Hitachi P-N23NA2 Service Manual

1 General information
Productclassicationandline-up
SMGB0099 rev.0 - 12/2016
4
1.3 Product classication and line-up
1.3.1 Classication of indoor unit models
Unittype(indoorunit):RCI,RCIM,RCD,RPC,RPI,RPIM,RPK,RPF,RPFI
Position-separatinghyphen(xed)
Capacity(HP):0.6,0.8,1.0,1.5,2.0,2.5,3.0,4.0,5.0,6.0,8.0,10.0,16.0,20.0
FS=SYSTEMFREE
N=R410Arefrigerant
H=Hotel(RPK-(0.6-1.5)only)
2/3/4=series
P=Pair
E=MadeinEurope
M=MadeinMalaysia
–=MadeinJapanorChina
(-DU)=DrainUp(RPIMonly)
(-f)=Non-ammableinsulation(RPI-(8.0-20.0)FSN3E-fonly
XXX – X.X FS N (H) X (P) (X) (-xx)
1.3.2 Classication of KPI models
KPI-Ventilationsystem
Position-separatinghyphen(xed)
Capacity(m
3
/h):250,500,800,1000,1500,2000
2=1~230V50Hz
E=Energyrecovery
X=Active(Energyrecovery+DXsection)
4=series
E=MadeinEurope
KPI – (Y)YY 2 Y 4 E
1.3.3 Classication of DX-Interface models
DX-Interfacetype
Position-separatinghyphen(xed)
Capacity(HP):2.0,2.5,3.0,4.0,5.0,6.0,8.0,10.0
E=MadeinEurope
2=series
EXV – X.X E 2
1.3.4 Classication of Econofresh models
Econofreshunittype
Position-separatinghyphen(xed)
Capacity(HP):4.0,5.0,6.0
N:R410Arefrigerant
E=MadeinEurope
EF - 456 N E
