9 Servicing
RPIM-(0.6-1.5)FSN4E - Ducted indoor unit
SMGB0099 rev.0 - 12/2016
306
9.8.5 Removal of the oat switch
? NOTE
To disconnect and remove the oat switch, previously see the chapter
corresponding to the wiring diagrams in this Manual.
1 Remove the necessary covers to access the oat switch.
2 Loosen the screws securing the oat switch to the support.
? NOTE
The torque value of the resin nut is 0.3 - 0.4 Nm. If the torque value is
higher, the nut will be damaged.
Nº Part
1 Float switch position
3 Loosen the resin nut securing the oat switch and remove it.
Nº Part
1 Float switch
9.8.6 Removal of the air lter
1 Remove the air lter xture support screws and remove the air
lter.
Nº Part
1 Air lter xture bar
2 Pull the air lter downwards.
Nº Part
1 Air lter
2 Screws
3 Air lter xture bar
