2 Unit installation
KPI energy and KPI active unit
SMGB0099 rev.0 - 12/2016
71
2
Example of installation:
1
2
3
4
5
6
Nº Name
1 EA (exhaust air outlet)
2 OA (outside air intake)
3 Return air grille
4 Supply air grille
5 Service space
6 Service access panel
Example of installation:
Deep hood
(to prevent rainwater from seeping in)
Anchor bolt
(to the provided by user)
Inspection opening
Supply
air grille
SA
(Supply
air)
RA
(Return
air)
Return
air grille
OA
(outdoor air intake)
EA
(exhaust air outlet)
