Model IFP-2000/ECS Installation Manual 151430-L8
9-15
Table 9-4: Menu choices for Internal/External Power Module
Choices Type Selections
Function
Selections for
each Type
Comments
Enter Point
Select Type UNUSED
B NOTIF NOTIF OUTPUT User also has Supervised/
Unsupervised option
CONTROL CIRCUIT
A NOTIF Same as B NOTIF
AUX_PWR CONSTANT Constant auxiliary power.
AUX RESET Resettable auxiliary power.
AUX DOOR Door holder auxiliary power.
B SWITCH MANUAL PULL Refer to comments column of
Table 9-3 for description of these options.
Latch or Non-latching feature only appears
for WATERFLOW, FIRE SUPERVISORY,
FIRE TAMPER, ZONE AUX1, ZONE AUX2,
SYSTEM AUX1, SYSTEM AUX2, ECS
INPUT, ECS TAMPER, and ECS
SUPERVISORY.
User also has ECS Event Number 1-8 option
for ECS INPUT.
Only available when an ECS-VCM is
installed in the system.
WATERFLOW
FIRE SUPERVISORY
FIRE TAMPER
FIREDRILL
SILENCE
RESET
P.A.S. ACK
ZONE AUX1
ZONE AUX2
SYSTEM AUX1
SYSTEM AUX2
MANUAL RELEASE
INTERLOCK
STATUS POINT
ECS INPUT
ECS TAMPER
ECS SUPERVISORY
A SWITCH Same as B SWITCH
B DETECT 2-WIRE SMOKE Used for Class B, 2-wire detectors.
4-WIRE SMOKE Used for Class B, 4-wire detectors.
4-WIRE CO SMK Used for Class B, 4-wire CO detectors.
A DETECT 2-WIRE SMOKE Used for Class A, 2-wire detectors.
4-WIRE SMOKE Used for Class A, 4-wire detectors.
CO 4-WIRE DET Used for Class A, 4-wire CO detectors.
Select Zone/Group Group or Zone selection will appear
depending on the type selected.
Edit Name See Appendix B.
