Honeywell Performance Series User Manual

Web Client Operation
171
2. Click the Edit icon for the Ethernet connection that you want to modify. The Edit screen
opens.
Figure 12-37 Edit TCP/IP Screen
3. Make any changes to the TCP/IP settings as needed, and then click OK.
Table 12-12 TCP/IP Configurations
Configuration Description
Mode
There are two modes: STATIC and DHCP.
• The IP address, subnet mask, and gateway is inactive and not
configurable when you select the DHCP mode to automatically
search for the IP address.
• If you select STATIC mode, then you need to manually configure the
IP address, subnet mask, and gateway.
• If you select DHCP mode, then you can only view the IP address,
subnet mask, and gateway. You cannot configure these values.
• If you switch from the DHCP mode to the static mode, then you
need to reset the IP parameters.
• • The IP address, subnet mask, gateway, and DHCP are read-only
values when the PPPoE dial is OK.
MAC Address Displays the MAC address. This field is not configurable.
MTU Use the default MTU (maximum transmission unit) value.
IP Version
Select the IP version, either IPv4 or IPv6.
You can use either version to access the camera’s IP address.
IP Address
1. Use your PC’s keyboard to enter the IP address.
2. Set the Subnet mask and Default gateway.
Subnet Mask If you selected the STATIC mode, then enter a Subnet Mask value.
Default Gateway If you selected the STATIC mode, then enter a Default Gateway value.
Preferred DNS Enter the DNS IP address.
Alternate DNS Enter an alternate DNS IP address.

Honeywell Performance Series Specifications

General

IR Range	Up to 30m (98ft)
Weatherproof Rating	IP66
Power Supply	PoE (Power over Ethernet) IEEE 802.3af, 12 VDC
Image Sensor	1/2.8" CMOS
Vandal Resistance	IK10
Video Compression	H.265/H.264/MJPEG
Storage	MicroSD card slot (up to 256GB)
Network Connectivity	10/100 Mbps Ethernet
