Honeywell Performance Series User Manual

Web Client Operation
219
Note
This function is only available for
HEN081*4/HEN162*4/HEN163*4/HEN161*4/HEN322*4/HEN323*
4/HEN321*4/HEN642*4/HEN643*4.
In the Custom Split interface, you can configure a customized split screen display.
1. Click the Custom Split tab in the DISPLAY configuration interface under System to open
the Custom Split configuration interface.
Figure 12-94 Custom Split Configuration Interface
2. On the Custom Split tab, click to add the selected split view to the list.
3. Use the mouse to click and drag the display grid to configure it, as needed. You can
combine small squares into a larger display area, or split them up to view more channels
at once. To use the custom split window, click on the main window (see Figure
12-12).
4. Click OK to save your settings.
RS232 Configurations
Note
This function is only available for
HEN081*4/HEN162*4/HEN163*4/HEN161*4/HEN322*4/HEN323*
4/HEN321*4/HEN642*4/HEN643*4/HEN04103L/HEN08103L/HE
N16103L/HEN32103L.
1. Click RS232 under System to open the RS232 configuration interface.

Honeywell Performance Series Specifications

General

IR Range	Up to 30m (98ft)
Weatherproof Rating	IP66
Power Supply	PoE (Power over Ethernet) IEEE 802.3af, 12 VDC
Image Sensor	1/2.8" CMOS
Vandal Resistance	IK10
Video Compression	H.265/H.264/MJPEG
Storage	MicroSD card slot (up to 256GB)
Network Connectivity	10/100 Mbps Ethernet
