HP 1660 Series User Manual

Performance Test Record (oscilloscope)
Test Settings Results
Bandwidth
Channel 1
Channel 2
Limit
≤−3.0dB
≤−3.0dB
Measured
________
________
Time
Measurement
Accuracy
5.500ns
± 150ps
99.00ns
± 155ps
MEAN X-O
MIN X-O
MEAN X-O - MIN X-O
MAX X-O
MAX X-O - MEAN X-O
MEAN X-O
MIN X-O
MEAN X-O - MIN X-O
MAX X-O
MAX X-O - MEAN X-O
________
________
________
________
________
________
________
________
________
________
Trigger
Sensitivity
Channel 1
Channel 2
Trigger Stable @ 100mVp_p
Trigger Stable @ 200mVp_p
Trigger Stable @ 100mVp_p
Trigger Stable @ 200mVp_p
Pass/Fail
Pass/Fail
Pass/Fail
Pass/Fail
________
________
________
________
Performance Test Record (oscilloscope)
3–103

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
