HP 1660 Series Replaceable Parts
Ref.
Des.
HP Part
Number QTY Description
Exchange Board Assembly
01660-69503 Exchange Board Assembly - CPU
01660-69501 Exchange Board Assembly-ACQ 128 CH (HP 1660A, HP 1660AS)
01660-69504 Exchange Board Assembly-ACQ 96 CH (HP 1661A, HP 1661AS)
01660-69505 Exchange Board Assembly-ACQ 64 CH (HP 1662A, HP 1662AS)
01660-69506 Exchange Board Assembly-ACQ 32 CH (HP 1663A, HP 1663AS)
01660-69520 Exchange Board Assembly-Oscilloscope (HP 1660AS-series only)
HP 1660 Series
A1 01660-66503 1 Board assembly - CPU
A2 01660-66501 1 Board assembly-ACQ 128 CH (HP 1660A)
A2 01660-66504 1 Board assembly-ACQ 96 CH (HP 1661A)
A2 01660-66505 1 Board assembly-ACQ 64 CH (HP 1662A)
A2 01660-66506 1 Board assembly-ACQ 32 CH (HP 1663A)
A3 01660-66502 1 Board assembly-keyboard
A4 01660-61901 1 Switch Actuator
A5 01650-61601 1 Monitor sweep cable
A6 01650-61608 4 Probe tip assembly (HP 1660A, HP 1660AS)
A6 01650-61608 3 Probe tip assembly (HP 1661A, HP 1661AS)
A6 01650-61608 2 Probe tip assembly (HP 1662A, HP 1662AS)
A6 01650-61608 1 Probe tip assembly (HP 1663A, HP 1663AS)
A7 0950-2261 1 Power supply
A8 0950-2169 1 Disk drive
A9 2090-0304 1 Monitor assembly
A10 3160-0429 1 Fan-tubeaxial
A11 16550-61601 4 Probe cable (HP 1660A, HP 1660AS)
A11 16550-61601 3 Probe cable (HP 1661A, HP 1661AS)
A11 16550-61601 2 Probe cable (HP 1662A, HP 1662AS)
A11 16550-61601 1 Probe cable (HP 1663A, HP 1663AS)
A12 01660-66520 1 Board Assembly-Oscilloscope (HP 1660AS-series only)
A13 54512-63402 2 Attenuator (HP 1660AS-series only)
E1 5959-9333 Replacement probe leads (5 per package)
E2 5959-9334 Replacement probe grounds (5 per package)
E3 5959-9335 Replacement pod ground (2 per package)
E4 5090-4356 Grabber kit assembly (20 grabbers per package)
F1 2110-0055 1 Fuse (4 A, 250 V)
H1 1400-0611 1 Clamp-cable
H2 01660-09101 4 Ground spring (HP 1660A, HP 1660AS)
H2 01660-09101 3 Ground spring (HP 1661A, HP 1661AS)
H2 01660-09101 2 Ground spring (HP 1662A, HP 1662AS)
H2 01660-09101 1 Ground spring (HP 1663A, HP 1663AS)
H3 01650-46101 2 Locking pin PCB
H4 01660-67601 2 BNC connector assembly
H5 6960-0149 2 Plug-D hole 0.500" (HP 1660A-series only)
H6 54503-87601 1 Plug-banana
H7 01660-09102 4 ESD clip
Replaceable Parts
Replaceable Parts List
7–5

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
