PCI Device 106
Table 8-5 Class: HP_PCISlot
Property name Property implementation
A string describing the full PCI slot location. If the
slot is empty, this is indicated.
Description
Examples:
Slot 2 or Slot 3 – Empty slot (non-cellular
systems)
Cabinet 8 Bay 0 Chassis 1 Slot 2 (cellular
systems)
A string describing the full PCI slot location. If the
slot is empty, this is indicated.
ElementName
Examples:
Slot 2 or Slot 3 – Empty slot (non-cellular
systems)
Cabinet 8 Bay 0 Chassis 1 Slot 2 (cellular
systems)
• True—if slot is powered on
PoweredOn
• False—if slot is not powered
Empty slots can be powered on or off, but the API does
not have a mechanism to determine the true state of
empty slots. Therefore, by default, empty slots are
indicated as powered on.
CIM_PhysicalConnector
• 0 (Unknown)
ConnectorLayout
• 1 (Other)
• 16 (PCI)
• 17 (PCI-X)
• 18 (PCI-E) if lane count is unknown; otherwise use
one of the following:
• 19 (PCI-E x1)
• 20 (PCI-E x2)
• 21 (PCI-E x4)
• 22 (PCI-E x8)
• 23 (PCI-E x16)
• 24 (PCI-E x32)
• 25 (PCI-E x64)
• PCI—This is a 33 MHz PCI slot
ConnectorPinout
• PCI-66—This is a 66 MHz PCI slot
• PCI-X—This is a PCI-X slot
• PCI Express—This is a PCI Express slot
• 43 (PCI)—if this is a 33 MHz PCI slot
ConnectorType
• 80 (PCI-66MHZ)—if this is a 66 MHz PCI slot
• 98 (PCI-X)—if this is a PCI-X slot
• 1 (Other)—if this is a PCI Express slot
