Smart Array 215
Table 15-28 Class: HPSA_DriveCageLocation (HP_Location)
Property name Property implementation
HPSA_DriveCageLocation
15.3.28HPSA_ArraySystemLocation
HPSA_ArraySystemLocation represents a location string for the array system.
Table 15-29 Class: HPSAArraySystemLocation (HP_Location)
Property name Property implementation
CIM_ManagedElement
Caption Controller name and location
Examples:
• Smart Array in Slot 3, for internal
• MSA500 in SystemCab03, for external
Description Controller name and location
Examples:
• Smart Array in Slot 3, for internal
• MSA500 in SystemCab03, for external
ElementName Controller name and location
Examples:
• Smart Array in Slot 3, for internal
• MSA500 in SystemCab03, for external
CIM_Location
Name Opaque key
PhysicalPosition Opaque key
HP_Location
• PCI Slot Number—when Adapter is specified in
ElementLocationTagDesc
ElementLocationTag
• Chassis Name—when Chassis is specified in
ElementLocationTagDesc
• 23 (Adapter)—for internal HBAs
ElementLocationTagDesc
• 3 (Chassis)—for External Storage systems
LocationInformation[0] For internal HBAs: PCI Slot number
Examples:
• 3 – PCI Slot 3
• 0 – Embedded on Motherboard
Not Required for External Storage systems
• 3 (PCI Slot)—for internal HBAs
LocationInfoDesc[0]
• Not required for External Storage Systems
HPSA_ArraySystemLocation
