System Power Supply 53
Table 4-3 Class: HP_PowerCollection
Property name Property implementation
GroupOperationalStatus[0] Represents the most severe power redundancy status
and non-fault tolerant power supply operational status:
• 0 (Unknown) —If power collection status is
unknown
• 2 (OK) —If power supplies are operating properly
• 3 (Degraded) —If no
HP_WinPowerSupply.OperationalStatus[0] for all
non-fault tolerant power supplies report 6 (Error)
and
HP_WinPowerRedundancySet.RedundancyStatus
for any power redundancy sets report 3
(Degraded Redundancy) or 4 (Redundancy Lost)
and no power redundancy sets report 5 (Overall
Failure). If the system starts up with a redundancy
status set to 4 (Redundancy Lost) and no power
supplies were removed or failed,
GroupOperationalStatus is set to 2 (OK) because
this is a valid configuration.
• 6 (Error) —If
HP_WinPowerSupply.OperationalStatus[0] for
any non-fault tolerant power supplies report 6
(Error) or if
HP_WinPowerRedundancySet.RedundancyStatus
for any power redundancy sets report 5 (Overall
Failure).
Note: If the system starts up with a redundancy status
set to 4 (Redundancy Lost) and no power supplies have
been removed or failed, the GroupOperationalStatus is
set to 2 (OK) because this is a valid configuration.
GroupStatusDescriptions[0]
• Unknown status for power supplies, if
GroupOperationalStatus[0] is 0 (Unknown).
• Power supplies are operating
properly, if GroupOperationalStatus[0] is 2
(OK).
• Fault tolerant power supplies are
degraded, if GroupOperationalStatus[0] is 3
(Degraded).
• Power supplies have failed, if
GroupOperationalStatus[0] is 6 (Error).
4.3.3HP_PowerRedundancySet
HP_PowerRedundancySet is used to model power supply redundancy sets on Integrity servers. The
Windows implementation class is HP_WinPowerRedundancySet.
Table 4-4 Class: HP_PowerRedundancySet
Property name Property implementation
