Smart Array 211
Table 15-23 Class: HPSA_SCSIProtocolEndpoint (CIM_SCSIProtocolEndpoint)
Property name Property implementation
ElementName Controller name and location (for example, Smart
Array in Slot 3)
CIM_ManagedSystemElement
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault 2 (Enabled)
RequestedState 12 (Not Applicable)
CIM_ServiceAccessPoint
CreationClassName HPSA_SCSIProtocolEndpoint
Name HBA Serial Number
SystemCreationClassName HPSA_ArraySystem
SystemName HPSA_ArraySystem.Name
CIM_ProtocolEndpoint
ProtocolIFType 0 (Unknown)
CIM_SCSIProtocolEndpoint
ConnectionType The supported connection type for this endpoint.
• 1 (Other)
• 3 (Parallel SCSI) for SCSI controllers
• 8 (SAS) for SAS controllers
OtherConnectionType The connection type if ConnectionType is 1 (Other).
• 0 (Unknown)
Role
• 2 (Initiator)
• 3 (Target)
• 4 (Both Initiator and Target)
HPSA_SCSIProtocolEndpoint
15.3.23HPSA_SCSIProtocolController
HPSA_SCSIProtocolController represents a view a SCSI resources on the Array Controller.
Table 15-24 Class: HPSA_SCSIProtocolController (CIM_SCSIProtocolController)
Property name Property implementation
CIM_ManagedElement
ElementName Controller name and location (for example, Smart
Array in Slot 3)
CIM_ManagedSystemElement
